Moog Voyager Modular Synth Interface is designed to bring all the controller outputs from the Voyager to 1/4″ Jack Sockets in a modular form. The control ranges can be set to be compatible with the system it is installed in.
The connection to the Voyager is via the 25way D connector, no internal adjustments are needed and the outputs are fully buffered and protect the Voyager when the modular unit is not powered on.
Specification:
5U x 2H
Voltage is +/-12V or +/-15V
Current 40mA on each rail
Voyager Keyboard @ 1V/Octave
Range +/-2 Octaves
Glide 1mS – 10S
Noise, LFO +/-5V
Key Gate 0-5V or 0-10V or S-Trigger
Re-trigger 0-5V or 0-10V or S-Trigger
Touch Gate 0-5V or 0-10V or S-Trigger
All other outputs 0-5V or 0-10V
